Cairn Research Laser Light Sources

BioVision Technologies offers the following laser-based microscope illumination products from Cairn Research, Ltd.:

Cairn Research Logo

MultiLine-LaserBank

The MultiLine-LaserBank is a modular and versatile laser launch system that allows for use of up to six solid-state lasers from multiple manufacturers. It is ideal for TIRF, spinning disk confocal, FRAP and optogenetic applications or any combination of these with multiple outputs via single or multi-mode fibers. It provides the convenience of a customizable, turnkey system at about half the cost of similar products.

It is upgradeable and alignable on-site, and is also designed as a standalone unit for biophysics laboratories to house their own lasers. Mechanical shutters and galvanometer switching modules are available as required. Lasers can be controlled using the Cairn MultiLine controller with computer and / or front panel digital and analogue modulation, or used with the laser manufacturer or other third-party power supply.

Applications:

  • Spinning disk and other multipoint confocal imaging
  • Point-scanning confocal imaging
  • Multi-channel TIRF
  • FRAP
  • Photolysis
  • Optogenetics

Key Benefits:

  • Houses upto six laser modules
  • Configured with up to eight singlemode or multimode fibre outputs
  • Flexible combination of wavelengths
  • User serviceable and configurable (subject to appropriate training)
  • Can be upgraded without return to base
  • Analogue and digital modulation and mechanical shutters
  • Multiple interlocks
  • Fast galvonometer switching option

TriLine-LaserBank

The TriLine-LaserBank is a modular and versatile laser launch system that allows for use of up to three solid-state lasers from multiple manufacturers. It is ideal for TIRF, spinning disk confocal, FRAP and optogenetic applications or any combination of these with multiple outputs via single or multi-mode fibers. It provides the convenience of a customizable, turnkey system at about half the cost of similar products.

It is upgradeable and alignable on-site, and is also designed as a standalone unit for biophysics laboratories to house their own lasers. Mechanical shutters and galvanometer switching modules are available as required, and a safety shutter is included as standard. Lasers can be controlled using the Cairn MultiLine controller with computer and / or front panel digital and analogue modulation, or used with the laser manufacturer or other third-party power supply.

Applications:

  • Spinning disk and other multipoint confocal imaging
  • Point-scanning confocal imaging
  • Multi-channel TIRF
  • FRAP
  • Photolysis
  • Optogenetics

Key Benefits:

  • Houses up to three laser modules
  • Configured with up to three singlemode or multimode fibre outputs
  • Flexible combination of wavelengths
  • User serviceable and configurable (subject to appropriate training)
  • Can be upgraded without return to depot
  • Analogue and digital modulation and mechanical shutters
  • Multiple interlocks

Need a product demo? Contact us.
